品牌  Brand

苏华特      SUHUATE

型号  Type

SHT2675

电 器 系 统

  Electrical system

电控  Electric control

48V 智能化控制系统；无级调速 ，制动断电 ，欠压保护 ，过 流保护等性能 ，稳定。48V大功率控制器，强劲快速。60V intelligent control system. It features stepless speed regulation, brake power cut-off, undervoltage protection and overcurrent protection with stable performance. Equipped with 48V high-power controller for strong power and fast response.

锂电池  Lithium battery

48V20Ah 磷酸铁锂电池

48V20Ah Lithium iron phosphate battery

电机    Motor

48V500W无刷直流电机48V500WBrushless Direct Current Motor

充电器   Charger

48V充电平稳、耐高温With 48V, the charging process is stable and it can withstand high temperatures.

充电时间   Charging time

6-8 小时 6-8hours

音响    Audio system

电喇叭Electric horn

车 身 配 置

  Body matching

车体  Body

钢制车架+塑料外壳  Steel frame + plastic shell

仪表台  Dashboard

多功能液晶数码仪表盘 ，功能齐全Dashboard: Multi - function LCD digital instrument panel with complete functions.

车架  Frame

摩托款车架，高强度钢结构件.Motorcycle-style frame, high-strength steel structural parts

灯光及信号  Lights and signals

前照灯 ，前后转向灯 ，组合后尾灯 ，电喇叭；凌厉霸气的水 晶的前大灯 ，按照仿生学原理设计 ，外形更美观 ，照明更安全Headlights, front and rear turn signals, combined rear   taillights, and an electric horn. The sharp and imposing crystal headlights are designed in accordance with the  principles of bionics, featuring a  more aesthetically  pleasing appearance and ensuring safer illumination.

颜色  Color

客户可定制   which can be customized by customers.

后视镜Rearview mirrors

左右各一手动型外后视镜Rearview mirrors: One manual external rearview mirror on each of the left and right sides.

座椅  Seat

整体式海绵外包皮革座椅 ，舒适耐用。Seat: Integrated sponge seat covered with leather, which is comfortable and durable.

底 盘

 Bottom plate

座额定乘员Rated passenger capacity

2 人（含驾驶员）   2 persons (including the driver).

初速 30km/h 制动距离    Braking distance at an  initial speed of 30km/h

≤6.5 m

动力传动系统   Power transmission system

无级调速系统   Stepless speed control system

驱动系统    Drive system

后轴驱动    Rear axle drive

减震Shock absorption

前：液压 / 后：弹簧F: hydraulic/R: spring

制动系统    Brake system

前碟刹,后鼓刹Front disc brake and rear drum brake

外形尺寸 长*宽*高(mm)Size Length * Width * Height (mm)

1810×730×1305mm

轴距    Wheelbase

1300mm

轮胎    Tyre

前轮：3.0-10    后轮3.0-10 ，耐磨防刺穿 ，品牌真空轮胎Front tire: 3.0-10   Rear tire: 3.0-10  Wear-resistant and puncture-proof   Brand vacuum tire

整车装备质量Vehicle curb weight

81kg

整车载荷ehicle load-carrying capacity

200kg

制动距离Braking distance

≤6.5 m

最大行驶速度 Maximum travel speed

≤40km/h

续驶里程    Range

≤50Km

最大爬坡度Maximum gradient

≤ 20%

充电输入电压 Charge input voltage

220v
