品牌  Brand

苏华特      SUHUATE

型号  Type

SHT2671

电 器 系 统

  Electrical system

电控  Electric control

大18管100A/300A    Large 18-tube 100A/300A

电池 battery

/

电机    Motor

72V3000W  最大功率6.7KW、额定功率3KW、最大扭矩200N.m

72V 3000W, maximum power 6.7kW, rated power 3kW, maximum torque 200N·m

充电器   Charger

72V 充电平稳、耐高温With 72V, the charging process is stable and it can withstand high temperatures.

充电时间   Charging time

6-8小时 6-8hours

音响    Audio system

电喇叭Electric horn

车 身 配 置

  Body matching

车体  Body

钢制车架+塑料外壳  Steel frame + plastic shell

仪表台  Dashboard

多功能液晶数码仪表盘 ，功能齐全Dashboard: Multi - function LCD digital instrument panel with complete functions.

车架  Frame

高钢燃油车车架  High-strength steel fuel vehicle frame

灯光及信号  Lights and signals

前照灯 ，前后转向灯 ，组合后尾灯 ，电喇叭；凌厉霸气的水 晶的前大灯 ，按照仿生学原理设计 ，外形更美观 ，照明更安全Headlights, front and rear turn signals, combined rear   taillights, and an electric horn. The sharp and imposing crystal headlights are designed in accordance with the  principles of bionics, featuring a  more aesthetically  pleasing appearance and ensuring safer illumination.

颜色  Color

科技灰/拉菲红  Tech Grey / Lafite Red

后视镜Rearview mirrors

左右各一手动型外后视镜Rearview mirrors: One manual external rearview mirror on each of the left and right sides.

座高 Seat height

785mm

底 盘

 Bottom plate

座额定乘员Rated passenger capacity

2 人（含驾驶员）   2 persons (including the driver).

初速 30km/h 制动距离    Braking distance at an  initial speed of 30km/h

≤6.5 m

动力传动系统   Power transmission system

无级调速系统   Stepless speed control system

驱动系统    Drive system

后轴驱动    Rear axle drive

减震Shock absorption

前悬挂系统：倒置液压阻尼减震、后悬挂系统：可调式后减。

Front Suspension System: Inverted hydraulic damping shock absorber; Rear Suspension System: Adjustable rear shock absorber.

制动系统    Brake system

前碟刹,后碟刹 ，性能优越Front disc brake, rear disc brake, superior performance.

外形尺寸 长*宽*高(mm)Size Length * Width * Height (mm)

1950×820× 1065 mm

轴距    Wheelbase

1360 mm

车轮

前轮：110/60-17   后轮140/70-16  ，真空轮胎。轮毂：铝合金铸造式。

Front wheel: 110/60-17, Rear wheel: 140/70-16, tubeless tires. Wheel hub: cast aluminum alloy.

整车装备质量Vehicle curb weight

150kg

整车载荷ehicle load-carrying capacity

350kg

制动距离Braking distance

≤6.5 m

最大行驶速度 Maximum travel speed

≤85km/h

续驶里程    Range

≤80Km

最大爬坡度Maximum gradient

≤ 20%

充电输入电压 Charge input voltage

220v

其他亮点Other highlights

定速巡航/远程遥控/倒挡功能/三挡变速/LED透镜大灯

Cruise Control / Remote Control / Reverse Gear Function / Three-speed Transmission / LED Lens Headlights
