型号Model

TDT010Z

电器系统

Electrical System

电控Electronic Control

48V控制器48V Controller

电池Battery

48V 20AH铅酸电池

48V 20AH Lead-acid Battery

电机Motor

48V400W电机 48V 400W Motor

充电器Charger

48V充电器 48V Charger

充电时间Charging Time

6-8小时6–8 h

车身配置

Body Configuration

外形尺寸 长*宽*高

Overall Dimensions L×W×H(mm)

1560×660×1050

载重Load Capacity

75kg

车身外壳Body Shell

车身配置前档塑料外壳，防雨防风护膝

Equipped with front plastic fairing

for rain and wind protection at knees

轮胎Tire

14×2.5 真空轮胎，铁圈

14×2.5 tubeless tire with steel rim

颜色Color

白、蓝巡逻车标准颜色

Standard patrol vehicle colors:

white and blue

驱动方式Drive Type

后轮驱动Rear-wheel Drive

制动系统Braking System

前后鼓刹Front and Rear Drum Brakes

整车装备质量Curb Mass(kg)

55kg

轴距Wheelbase(mm)

1125mm

干态：速度25km/h双闸制动距离

Dry condition:

 Braking distance at 25 km/h

with dual brakes

7m

干态：速度25km/h单后闸制动距离

Dry condition:

Braking distance at 25 km/h

with rear brake only

15m

湿态：速度16km/h双闸制动距离

Wet condition:

 Braking distance at 16 km/h

 with dual brakes

5m

湿态：速度16km/h单后闸制动距离

Wet condition:

Braking distance at 16 km/h

with rear brake only

10m

最大行驶速度

Maximum Speed(km/h)

25km/h

续驶里程Driving Range(km)

60km

最大爬坡度

Maximum Gradeability

≤12°

充电输入电压

Charging Input Voltage

220V

尾箱Rear Trunk

增配后尾箱Optional Rear Trunk

警灯警具喊话器系统Police Light, Warning Equipment and Loudspeaker System

巡逻灯具

Patrol Warning Lights

车前配置圆形警用红、蓝 警示爆闪灯；

配备可伸缩后杆式警用LED警灯警具；

配备高科技喇叭、喊话器系统，

安全、美观、大方；

警灯警具控制器、扬声器；

扬声器，采用铝合金材质，

牢固、响亮、耐用、

颜色为警白。防雨防晒，

耐低温、抗高温，

环境适应性强，

让巡逻形成一道威武亮丽的风景线。

A round police red and blue strobe

warning light is mounted at the front.

 A retractable rear pole-mounted police

LED warning light assembly is fitted.

 High-performance horn and

public address system are provided for safety,

good appearance and elegant design.

The system includes warning light

controller and loudspeaker.

 The loudspeaker is made of aluminum alloy,

 featuring sturdiness,

high volume and durability in police white finish.

 It is rainproof, sun-proof,

resistant to low and high temperatures

with strong environmental adaptability,

presenting an imposing

and striking appearance during patrol missions.
